Product Description
Extreme slope stabilization and severe erosion control require engineering materials that go beyond standard netting. Our multilayer reinforced Macmat is an advanced composite geomat that integrates mechanical strength with profound ecological restoration capabilities. It features a sophisticated three-layer (or multi-layer) structure: a high-tensile hexagonal steel wire mesh base, an intermediate layer (such as short-fiber geotextile to prevent soil loss, plastic geogrid for dual reinforcement, or coconut fiber mat for moisture/fertilizer retention), topped with a 3D polymer mesh pad. This synergy instantly halts soil erosion while creating an ideal micro-environment for rapid vegetation root growth.
Manufacturing this highly technical product requires absolute precision, a standard our factory meets through specialized multi-process equipment. The core steel wire (tensile strength ≥35 kN/m) is coated with heavy Galfan (5% Al-Zn + RE, 230–250 g/m²) and strictly passes the EN 10223-3 winding test without peeling. The polymer pad boasts a >90% porosity and retains ≥80% of its strength after UV aging. Recognizing the lack of a single mandatory international standard, we define every technical specification (SOW) meticulously in our contracts. Supported by CNAS/CMA or SGS third-party testing, we deliver a customized, REACH/RoHS compliant ecological armor for global civil and hydraulic engineering projects.
Specifications
|
Structure |
Steel wire mesh + Interlayer (Geotextile/Geogrid/Coir) + 3D polymer mat. |
|
Wire Strength & Coating |
Tensile ≥35 kN/m; Galfan coating (230–250 g/m²); Passes EN 10223-3. |
|
Polymer Mat |
Porosity >90%; Tensile ≥1.5–3 kN/m; UV retention ≥80%. |
|
Composite Peel Strength |
≥30 N/mm. |
|
Overall Weight |
Customized (commonly 600–1680 g/m²). |
Applications
Steep highway and railway embankment stabilization.
Riverbank erosion control and hydraulic channel lining.
Landfill capping and mine ecological restoration.
Coastal defense against storm surges and wave action.
Customization & Factory Strength
Our R&D team excels at complex laminations. Whether your project requires geotextiles for fine soil retention or coconut coir for rapid greening, we manufacture exactly to your engineering drawings. We provide comprehensive pre-sales consultation to lock in EN 10223-3 or ASTM D6693 testing parameters, ensuring total compliance with your region's geotechnical standards.
Packaging & Shipping
The composite mat is rolled tightly and wrapped in UV-resistant, waterproof film. We arrange shipping via FOB or EXW, providing bespoke factory inspection reports and certificates of origin upon dispatch.
FAQ
Q: Can you manufacture the Macmat based on our specific project's technical requirements?
A: Yes. Because there is no universal standard, we highly encourage you to provide your technical drawings and SOW. We will customize the composite layers to match your exact needs.
Q: Do you accept third-party inspections?
A: Absolutely. We frequently work with SGS, BV, and CNAS/CMA labs to verify peel strength, tensile strength, and Galfan coating weights.
Q: What is the delivery time for custom-made composite products?
A: For customized multi-layer composites, production and delivery typically occur within 30 to 60 days.
