Strong Bonding for Tough Sea Conditions
This mesh helps keep oil pipelines stable on the seabed. Strong underwater currents can cause pipelines to shift or vibrate. Our product serves as a counterweight mesh, securely holding the concrete coating around the pipe. This helps prevent excessive movement of the pipeline.
The mesh also helps the anti-corrosion coating form a complete protective layer around the pipe. This barrier keeps seawater away from the pipeline and reduces the risk of corrosion. We call this approach "engineered to fit, not forced to work."
Simple Design That Works Well with Concrete
We manufacture this oil pipeline counterweight mesh specifically for concrete coating applications. The wires are formed with special bends at uniform intervals along their length. This design allows the mesh to embed firmly into the concrete, acting as a strong internal reinforcement structure.
The wire ends protrude less than 1 mm, helping protect workers' hands during handling and production. All steel wires are hot-dip galvanized to provide excellent corrosion resistance. The zinc coating helps prevent rust inside the concrete, offering a simple yet highly durable solution.
Key Data You Can Trust
|
Parameter |
Technical Requirement |
Standard |
|
Mesh Type |
Longitudinal spaced bends; wire ends < 1 mm |
Refer to ASTM / Company Standard |
|
Mesh Opening |
Longitudinal: 25.4 or 50.8 mm (±2 mm); Width: ≥190.5 mm |
YB/T 5294 |
|
Chemical Makeup |
C ≤0.20%; Si ≤0.30%; Mn ≤0.70%; P, S ≤0.045% |
GB/T 4336 |
|
Zinc Coating |
Wire 2.0–2.3 mm: ≥55 g/m²; 2.3–2.85 mm: ≥65 g/m² |
ASTM A641 (Class 1) |
|
Strength |
Tensile Strength ≥485 MPa; Yield Strength ≥385 MPa; Elongation ≥12% |
ASTM A1064 |
|
Bend Test |
180° bend, ≥4 times, no cracks |
ASTM A1064 |
|
Weld Shear |
F ≥240 × A (F = breaking force in N; A = area in mm²) |
ASTM A1064 |
Why Buy This Oil Pipeline Counterweight Mesh
Our factory has specialized in manufacturing this mesh for more than 8 years. We focus exclusively on resistance-welded mesh products and maintain strict quality standards throughout production.
Our minimum order quantity starts from one full container. OEM services are also available-simply provide your drawings or specifications. You can customize the wire diameter, mesh spacing, and zinc coating weight to meet your project requirements.
We welcome third-party inspections from organizations such as SGS and BV. This same oil pipeline counterweight mesh has been used by CNPC and Shanghai Hilong in real-world projects. Proven field performance speaks louder than any brochure.
