The Heart of Your Filter System
Liquid streams often contain solid particles that can cause wear and damage to pumps and valves. A filter is used to remove these impurities, and the filter screen is the core component of the filtration system.
We manufacture it using a hook-needle weaving structure. We do not produce the outer housing-we focus on the core of your filtration system. This metal mesh filter screen helps protect your equipment and ensures stable operation.
Same Great Mesh for Many Uses
This product is the same type as our gas–liquid separation mesh. It is also referred to as mist catcher mesh or demister pad mesh. It is widely used in dust removal systems and oil–gas separation equipment.
Wire diameters range from 0.08 mm to 0.30 mm. We support single-wire weaving, multi-wire weaving, and metal fiber composite weaving structures.
Stainless steel is the most commonly used material, including grades 304, 304L, 316, and 316L. For highly corrosive environments, we also offer 904L, C276, 2205, and pure titanium materials.
This metal mesh filter screen provides stable and efficient clean output across a wide range of industrial applications.
Key Data Table
|
Parameter |
Technical Requirement |
Note |
|
Product Use |
Core filtration component |
Gas–liquid separation and solid particle removal |
|
Weave Type |
Hook-needle weave |
Specialized weaving process |
|
Wire Diameter |
0.08–0.30 mm |
Round or flat wire options |
|
Aperture Size |
2×4 mm, 4×5 mm, 7×? mm |
Selected based on filtration level |
|
Common Materials |
304 / 304L / 316 / 316L stainless steel |
Standard corrosion resistance |
|
Special Materials |
904L / C276 / 2205 / pure titanium |
High corrosion resistance applications |
Why Buy This Product
Our mesh features highly uniform pore distribution, ensuring consistent and stable filtration performance. The weaving points are structurally strong, preventing disintegration during backwashing processes.
We provide customized widths ranging from 100 mm to 600 mm. Small trial orders are accepted for testing and evaluation.
We also supply material certificates and full testing reports to ensure quality traceability.
Choose this metal mesh filter screen for reliable and long-term filtration performance.
