Stop Liquid Drops from Flying Away

This product is installed inside chemical towers. Gas streams often carry fine liquid droplets during operation. Conventional wire mesh cannot effectively capture these fine mists.

We use a special hook-needle weaving structure. Wire diameters are strictly controlled from 0.08 mm to 0.30 mm.

We do not simply sell mesh-we provide a high-performance mist elimination component. This demister mesh captures droplets that other systems fail to remove.

product-800-800

Core Part for Gas and Liquid Separation

This product is also known as mist eliminator mesh or mist catcher mesh. It is the core component of mesh pad mist eliminators and oil–gas separation systems.

We use stainless steel materials that provide excellent corrosion resistance and cost efficiency. The wire diameter range is broad, including single wire, multi-wire, and metal fiber composite weaving structures.

Common aperture sizes include 2×4 mm and 4×5 mm. Width options are also flexible, such as 100 mm, 150 mm, 300 mm, and 400 mm.

This demister mesh ensures clean gas output with efficient liquid removal performance.

Key Data Table

Parameter	Technical Requirement	Note
Other Names	Mist catcher, mesh pad	Used for gas–liquid separation
Weave Type	Hook-needle weave	Special structured weaving method
Wire Diameter	φ0.08 mm – φ0.30 mm	Common range: φ0.12–0.30 mm
Aperture Size	2×4 mm, 4×5 mm	Multiple configurations available
Wave Structure	20°–45° angle, 4–7 mm depth	Standard forming process
Common Widths	100, 150, 300, 400, 500, 550, 600 mm	Customized production available

Why Buy This Product

Our 304 and 316L stainless steel meshes are the most widely used materials in oil, gas, and chemical industries.

With 15 years of weaving experience, our factory ensures uniform mesh structure and consistent wire diameter control. Third-party inspections are supported upon request.

For highly corrosive environments, we also offer advanced materials such as 904L stainless steel or C276 nickel-based alloy.

Choose this demister mesh for efficient and reliable gas–liquid separation performance.
