Flexible Fence for Uneven Ground
Farms and rural areas often require fencing, but the ground is not always flat. Standard straight welded wire fences may leave gaps when installed on slopes.
We designed a mesh structure with horizontal wave bends. The entire roll forms a flexible wavy structure, allowing it to adapt better to uneven terrain. This is a lightweight and flexible fencing solution. This plastic coated welded wire mesh conforms better to ground variations.
PVC Coating for Outdoor Use
This product is also known as PVC-dipped welded wire mesh. The key difference from standard welded mesh is the wave-shaped structure of the horizontal wires. The entire roll is flexible and can only be supplied in roll form; it cannot be manufactured into flat panels.
It is widely used in outdoor fencing applications such as farmland, livestock enclosures, and general area separation.
The wire diameter ranges from 1.8 mm to 3.0 mm (after coating). Common mesh openings include 5×5 cm and 5×10 cm. The PVC coating thickness is at least 0.4 mm, ensuring strong weather resistance and long service life.
This plastic coated welded wire mesh is designed for long-term outdoor use.
Key Data Table
|
Parameter |
Technical Requirement |
Standard |
|
Other Name |
PVC-dipped welded mesh / plastic coated mesh |
Wave-structured fencing system |
|
Structural Feature |
Horizontal wires with wave bends |
Roll form only, not suitable for flat panels |
|
Wire Diameter |
1.8–3.0 mm |
Final coated size |
|
Mesh Opening |
5×5 cm / 5×10 cm |
Standard agricultural sizes |
|
Base Coating |
Hot-dip or cold galvanizing |
Complies with GB/T 33281-2016 |
|
PVC Layer Thickness |
≥0.4 mm |
Weather resistance and adhesion requirement |
|
Packaging Marking |
Material, specification, standard, origin, weight |
Includes CO, CIQ, MSDS, DoC |
Why Buy This Product
This product complies with the Chinese standard GB/T 33281-2016 and also meets environmental protection requirements of different target markets.
We recommend providing detailed technical specifications for accurate customization. This product does not have a unified global standard; therefore, we issue a formal declaration of conformity based on specifications.
All packaging includes clear product information for customs clearance and identification. We support payment by Letter of Credit (L/C).
Choose this plastic coated welded wire mesh for reliable and flexible fencing solutions in agricultural and ranch applications.
