Product Description
Masonry walls are inherently strong in compression but weak in tension, making them susceptible to cracking under thermal stress, vibration, or seismic activity. Our perforated brickwork reinforcement (stamped brick mesh) is a highly specialized architectural material designed to solve this exact problem. Unlike traditional woven or welded wire, this mesh is manufactured by intricately stamping and expanding thin galvanized steel or stainless steel plates (typically 0.35mm thick). The resulting structure features longitudinally aligned, elongated hexagonal meshes with a unique side-standing strand profile. Crucially, it incorporates widened edge ribs and a central V-shaped groove, creating an incredibly rigid skeleton when embedded in mortar.
Through continuous independent R&D and the utilization of specialized stamping equipment, our factory has perfected this reinforcement technology. The unique 3D structure of the V-groove and hexagonal mesh allows cement mortar to flow through and lock the mesh in place, creating a monolithic composite wall. This dramatically enhances the wall's tensile strength, pressure resistance, and ability to absorb earthquake tremors and temperature fluctuations. Supplied in continuous rolls (10-100 meters) and various widths (6cm to 30cm) to match standard brick dimensions, our perforated brickwork reinforcement is the hidden backbone of safe, crack-free modern masonry.
Specifications
|
Material |
Galvanized steel strip or Stainless steel plate. |
|
Standard Thickness |
0.35mm. |
|
Structure |
Stamped and expanded hexagonal mesh with side-standing strands. |
|
Key Features |
Widened edge ribs and a central V-shaped reinforcing groove. |
|
Dimensions |
Widths of 6cm, 10cm, 15cm, 20cm, 30cm; Lengths 10-100 meters/roll. |
Applications
Reinforcement of brick and hollow block masonry walls.
Foundation and retaining wall stabilization.
Prevention of wall cracking due to thermal expansion or vibration.
Seismic strengthening for residential and commercial buildings.
Customization & Factory Strength
With our specialized stamping lines, we offer full OEM/ODM services. If your architectural design requires a specific plate thickness, width, or material grade (such as 316 stainless for coastal construction), our R&D team can customize the tooling to produce exactly what you need, ensuring optimal stress absorption for your specific building project.
Packaging & Shipping
To prevent deformation of the delicate V-grooves, the mesh rolls are packaged in sturdy cartons, or placed on pallets and in wooden crates for bulk export. We support EXW and FOB shipping terms.
FAQ
Q: Can you manufacture based on our specific width and thickness requirements?
A: Yes, stamped metal products are a core specialty of our factory. We can adjust our stamping dies to meet your exact technical drawings and prototypes.
Q: Do you provide free samples?
A: Yes, we can provide a small sample of the stamped mesh so you can verify the V-groove structure and material thickness before placing a bulk order.
Q: How do you ensure on-time delivery?
A: We execute a scientific production schedule based on your delivery timeline, breaking the contract into phases and keeping you updated throughout the stamping process.
